WIND ENERGY CABLES

Reliable Cabling for Harsh Wind Environments

Wind turbines are installed in some of the world’s most demanding environments — from hilltops and deserts to seashores and offshore platforms. These locations expose systems to intense UV, mechanical stress, moisture, and extreme temperatures.

AEROLEX Wind Energy Cables are engineered to thrive under these harsh conditions, delivering durability, flexibility, and long-term performance. Installed in nacelles, towers, or turbine bases, these cables ensure seamless power transmission and signal integrity in both onshore and offshore wind energy installations.

  • High Flexibility & Torsion Resistance:
    Specially designed for dynamic bending and twisting in moving parts such as nacelles and pitch control loops.
  • UV & Weather Resistant:
    Built to withstand prolonged exposure to harsh environmental conditions including sunlight, rain, and salt spray.
  • Oil & Chemical Resistance:
    Excellent durability against mineral oils, synthetic lubricants, hydraulic fluids, cleaning agents, and coolants.
  • Temperature Resistant:
    Stable performance from -40°C to +105°C, with short-circuit resistance up to 250°C.
  • Environment Friendly:
    Made with halogen-free, low smoke, and recyclable materials for safer and greener installations.
  • Nacelle-to-Rotor Cable Connections
  • Tower Internal Wiring
  • Pitch and Yaw Control Systems
  • Generator and Transformer Interconnections
  • Onshore and Offshore Wind Farms
  • Rated Voltage: 0.6/1 kV
  • Max. Operating Voltage:
    • AC: 0.7/1.2 kV
    • DC: 0.9/1.8 kV
  • Test Voltage: 3 kV
  • Max. Conductor Temperature: 90°C
  • Short-Circuit Temp: 250°C
  • Working Temp Range: -40°C to +90°C
  • Standards:
    DIN VDE 0250, DIN VDE 0282, UL 758 (AWM Style 4537)
  • Conductor:
    Flexible bare copper wires (Class 5 as per IEC 60228)
  • Insulation:
    EPR-based thermoplastic rubber compound
  • Core Identification:
    According to HD 308
  • Sheath:
    UV & oil-resistant thermoplastic rubber compound

Backed by AEROLEX’s engineering excellence, our wind energy cables are a trusted choice for OEMs, EPC contractors, and renewable energy developers worldwide.
